The YABO 12V 100Ah LiFePO4 battery is an advanced deep-cycle lithium battery ideal for trolling motors, RVs, marine applications, and solar power storage. Lightweight and efficient, it features an integrated Battery Management System (BMS) for superior safety and longevity.
YABO 12V 100Ah LiFePO4 Battery with Bluetooth Monitoring
Product Features:
Electrical
Characteristics | Nominal Voltage | 12.8V |
Nominal Capacity | 100Ah@0.2C |
Energy | 1280Wh |
Internal Resistance | ≤50mΩ |
Cycle Life | 6000 Cycles |
Self Discharge | ≤3.5% per month at 25℃ |
Standard Charging | Max.Charging Voltage | 14.0~14.6V |
Charging Mode | At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and
then,changed continuously with constant voltage of 14.6V until the current was not
more than 0.02C |
Charging Current | 50A |
Max.Charging Current | 50A |
Standard Discharging | Discharging Current | 100A |
Max. Continuous Current | 100A |
Max.Pulse Current | 200A(<3S） |
Discharging Cut-off Voltage | 10.0 |
Operating Condition | Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
Water Dust Resistance | IP55 |
Structure | Cell & Format | Cylindrical cells and prismatic cells |
Casing | Plastic |
Dimension(L*W*H*TH) | 328*172*216*216mm |
Package Dimension | 398*243*295mm |
Weight | Approx. 13Kg |
Terminal | M8 |
Product Description:
The YABO Power 12V 100Ah LiFePO4 Battery is engineered for industrial-grade reliability. With 1280Wh output and 100% usable energy, it’s perfect for powering heavy-duty tools, backup systems, and commercial solar arrays. The IP55 housing keeps dust and moisture at bay, while the 100A BMS guarantees safe operation under high load conditions. Designed for 6000+ cycles, it reduces maintenance and replacement costs, delivering dependable energy year after year.
Keywords: industrial lithium battery 12V 100Ah, IP55 LiFePO4 for commercial use, heavy-duty deep cycle battery, renewable energy storage.
Bullet Points:
Built for industrial and commercial energy systems.
1280Wh capacity with 100% depth of discharge.
6000+ cycles & low-maintenance operation.
IP55 protection for dusty or damp environments.
100A BMS ensures stable high-load performance.
